Stereo Microscope Smtz

Standards

Laboratories

SMTZ microscope provides a high quality image thanks to the high quality objectives. The microscope is also equipped with a video head provided of a TFT LCD colour monitor 6.4’’, with adjustable inclination. The white balance function button ensures the greatest image accuracy reproduced on the monitor. An RCA Video output allows link with an external monitor and, on demand, a RCA-USB converter can allow the connection with a computer in order to acquire/edit images coming from the microscope. The zoom range of objectives is from 0.7X to 4.2X, with standard 10X eyepieces, gives a total zoom range that comes from 7X to 42X. This range can further be enlarged through optional additional lenses and eyepieces, up to a zoom range from 3.5X to 210X.The illumination can be configured with transmitted illumination or with reflected illumination or with boths well; ensuring in this way versatility for every kind of observation. The Video Head can also easily be removed to allow the use of CCD cameras or standard reflex/digital cameras. The Microscopes can be equipped nwith accessories like stands, illumination systems, additional lenses, CCD cameras.

TECHNICAL SPECIFICATIONS
• Observation head 45° tilted and 360° rotable
• Adjustable interpupillar distance from 53 up to 75 mm
• Diopter regulation ± 5 mm
• Wide angle eyepieces W A 10x, wide filed 31 -5,2 mm
• Zoom objectives 0,7X ÷ 4,2X
• External switching 100 ÷ 230 V AC – 50/60 Hz.- 12 VAC

EQUIPMENT
• Supplied with eyepieces 10x wide angle, white disk

Code Model Standard Goals Enlargements External dimensions Weight
GT0202 MICROSCOPE SMZT LCD WF 10x 3,5 x ÷ 210 x 450x350x250 mm 7 Kg
GT1552 MICROSCOPE SMTZ-CAM 5MP WF 10x 3,5 x ÷ 210 x 450x350x250 mm 7 Kg
Code Description Image
GT1068 Eyepieces WF 15X
GT1078 Eyepieces WF 20X
GT1079 Eyepieces WF 25X
GT1080 Objectives 0,5X
GT1081 Objectives 0,75X
GT1082 Objectives 1,5X
GT1083 Objectives 2x
GT1283 5 Mpixel CMOS color camera'
GT1091 RCA-USB converter & software
